Characteristics
| DC Operating Power | |
| Full Load Continuous Current | 10 A at 55°C 7 A at 70°C |
| AC Operating Power | |
| Power Input Configuration | 1-phase 3-phase |
| Power Input Frequency | dc, 50 to 500 Hz |
| Nominal Input Voltage | 120 ÷ 240 Vac 250 Vdc |
| Generator and Bus Voltage Sensing | |
| Configuration | 1-phase 3-phase–3-wire |
| 50 Hz Voltage Ranges | 100 Vac ±10% 200 Vac ±10% 400 Vac ±10% |
| 60 Hz Voltage Ranges | 120 Vac ±10% 240 Vac ±10% 480 Vac ±10% 600 Vac ±10% |
| Frequency | 50/60 Hz nominal |
| Burden | <1 VA per phase |
| Generator Current Sensing | |
| Configuration | 1-phase or 3-phase with separate input for cross-current compensation |
| Nominal Current | 1 Aac |
| Frequency | 50/60 Hz |
| Burden | <0,1 VA |
| Environmental | |
| Operating Temperature (10 A Continuous) | –40°C to 55°C |
| Operating Temperature (7 A Continuous) | –40°C to 70°C |
| Storage Temperature | –40°C to 85°C |
| Communication | |
| USB | USB type B port |
| Ethernet | RJ45 jack 10BASE-T 100BASE-TX |
Features
| Voltage regulation accuracy ±0,25% |
| THD-tolerant design offers reliable operation with nonlinear loads |
| True RMS three-phase generator voltage sensing/regulation |
Four excitation control modes:
|
| Auto tuning feature |
| Soft start and voltage buildup control |
| Integrated droop and cross current compensation |
| Diodes failure detection |
| Remote setpoint control input accepts analog voltage or current control signal |
| Real-time metering |
Wide range of limiting and protection functions:
|
| Eight programmable contact-sensing inputs |
| Three contact outputs |
| Flexible communication: Serial communication through USB port and Ethernet communication |
| Data logging and sequence of events |
| USB powered for programming via BESTCOMSPlus software |
